Product Description
Product name |
ultra thin Aluminum LED fabric light box |
Material |
Return Sides and back: high grade stainless steel or aluminum |
Processing |
Display face: flex banner, or colorful acylic(PMMA) plate |
Via laser cutting, fine welding, polishing, painting, screen printing and assembly by experienced senior technician. |
|
SHAPE |
Rectrangle, round, curved, etc |
Light type |
LED super bright diffuse reflector |
Colour |
White/black/golden/silver |
Poster print |
3P fabric,stretch ceiling, |
PROFILE |
60, 70, 100, 110, 120mm depth for single-sided; |
80, 140, 200mm for double-sided. |
|
LED Features |
Waterproof, energy saving and long lasting, over 50,000 hours quality guarantee |
Design |
Accept customization, various contents, shapes, sizes for your choice. You'd better give us the design drawing. Of course if not we can provide professional design service for you. |
ACCESSORIES |
Wall mounting , free-standing, ceiling, hanging parts are available |
Installation Method |
Screw bolts fixed. With 1:1 fixing template for installation reference |
Applicable places |
mobile phones, electrical appliances, catering ,clothing store, signs / posters, corporate culture ,wall, Exhibition hall, subway, Airport, bus stations, filling stations etc |
Average Lifetime |
50,000 hours |
Warranty |
2 years |
Package |
Covered with bubble wrap inside, and packed with wooden case outside. Also can be packed per your requirements |
Order Method |
70% down payment, balance before shipment |
Fabric light box is more and more used for indoor advertising display.The lightweight fabric poster on the front. Warm lighting makes suitable graphci photo for people.
ITEM: |
FRAME SIZE |
Viewing size |
Thickness |
FilmSize |
Packing size |
Volume |
Gross weight |
(Single-sided) |
(MM) |
(mm) |
(mm) |
(mm) |
(mm) |
(m3) |
(KG) |
3000*1500 |
2995*1495 |
65 |
3020*1520 |
3100*1600*100 |
0.5 |
41.8 |
|
2400*1200 |
2395*1195 |
2420*1220 |
2500*1300*100 |
0.33 |
29.3 |
||
1800*1200 |
1795*1195 |
1820*1220 |
1900*1300*100 |
0.25 |
22.4 |
||
A0 |
1189*841 |
1184*836 |
1209*861 |
1320*950*100 |
0.13 |
12.4 |
|
A1 |
841*594 |
836*589 |
861*614 |
970*770*100 |
0.07 |
7.7 |
|
A2 |
594*420 |
589*415 |
614*440 |
720*520*100 |
0.04 |
4.8 |
|
B0 |
1414*1000 |
1409*995 |
1434*1020 |
1550*1150*100 |
0.18 |
16 |
|
B1 |
1000*707 |
995*702 |
1020*727 |
1150*800*100 |
0.09 |
9.8 |
|
B2 |
707*500 |
702*495 |
727*520 |
830*700*100 |
0.06 |
6.1 |
Available at a length and width suitable for large format displays, the Soft film light box delivers bright and even light through LumiLattice, Matrix or SideBeam thus making it the perfect option to back-light modern and beautiful graphic displays.
Installation Notes
High level of appearance/Stronger performance/The dynamic of science and technology/Stable output/Multiple protection/Imported chip/Save energy/Life is long/The same ring/No stroboscopic
Title goes here.
1.Confirm the location and mark on the wall.
2.Drill hole and insert expansion screws.
3.Put the connectors on the frame.
4.Splice 4 corners and fix by screws.
5.Put the back panel on the frame then fix.
6.Put the frame on the wall.
7.Fix the LED light on the back panel .
8.Connect power supply with corresponding positive and negative wire.
9.Insert the 4 corners of the poster into frame .
10.Insert the rest parts of the poster into the frame.
11.Finished products.
Company Profile
Our Advantages
Certifications
Packing & Shipping
FAQ
Q1. How do we guarantee your quality?
Always sample verifying before mass order;Three production lines, with advanced facilities;Strict quality control before delivery;Professional Post-sale instructions for mounting.
Q2. What do we think is the biggest strength?
Our factory started offering raw materials for billboard market, guaranteeing a competitive price with good quality.
Q3. How to deal with the faulty?
Although Our products are produced in strict quality control with a defective rate less than 0.2%, we do have confidence in
post-sale services when that happens. During the guarantee period, we shall send new items, or repair and send back for large projects.
Q4. How to start a order?
First, we have a basic understanding of your requirements or application；
Second, we send a precise quotation for your reference；Third, we send you a sample；Finally, after your confirmation, we arrange manufacturing.
Q5. Can we offer free samples？
Yes. Customers can just fix the shipping charge to have our free samples.
Always sample verifying before mass order;Three production lines, with advanced facilities;Strict quality control before delivery;Professional Post-sale instructions for mounting.
Q2. What do we think is the biggest strength?
Our factory started offering raw materials for billboard market, guaranteeing a competitive price with good quality.
Q3. How to deal with the faulty?
Although Our products are produced in strict quality control with a defective rate less than 0.2%, we do have confidence in
post-sale services when that happens. During the guarantee period, we shall send new items, or repair and send back for large projects.
Q4. How to start a order?
First, we have a basic understanding of your requirements or application；
Second, we send a precise quotation for your reference；Third, we send you a sample；Finally, after your confirmation, we arrange manufacturing.
Q5. Can we offer free samples？
Yes. Customers can just fix the shipping charge to have our free samples.
